Snorkel TL37J
SNORKEL TOWABLE BOOM LIFT — TL37J
TRULY TOWABLE
The Snorkel TL37J is a high specification trailer-mounted boom lift. This highly maneuverable towable lift has fully proportional hydraulic & up-&-over access. Powered platform rotation & auto-leveling outriggers come as standard. This articulating boom also offer a bi-energy option for clean and quiet indoor use.
FEATURES
• 4ft 3in, 130° jib (1.3m jib with 130˚ working arc)
• In-line boom design for maximum rigidity
• Hydraulic stabilizers
• Hand pump emergency lowering from platform
• Lock valves on all hydraulic cylinders
• Proportional live hydraulic controls
• Power line to platform
• Dual lanyard attachment points
• 2 year parts & labor, 5 year structural warranty
OPTIONS
• Special paint colors
• Friction drive assist package
• Flashing amber light
• Work lights in platform
• Nylon spreader pads (set of 4)
• Environmental hydraulic oil
• Snorkel OnSite telematics
Specifications are subject to change without prior notice. Similar models may be shown in addition to the featured model. Equipment may be shown with options.
Specifications
| Stowed height | 6 ft 11 in |
|---|---|
| Superstructure rotation (non-continuous) | 700° |
| Jib arc | 130° |
| Stabilizer footprint | 12 ft 9 in x 10 ft 10 in |
| Towing width | 5 ft 3 in |
| Weight | 3,498 lbs |
| Max. working height | 41 ft 9 in |
| Wheels | 185R14C |
| Max. platform height | 35 ft 9 in |
| Jib length | 4 ft 3 in |
| Max. horizontal reach | 18 ft 5 in |
| Power options | Gasoline; bi-energy (combustion & battery); AC electric |
| Platform depth | 2 ft 4 in |
| Platform capacity (SWL) | 475 lbs |
| Towing length | 20 ft 11 in |
| Power source | 24V DC battery |
| Platform rotation | 160° |
| Controls | Hydraulic proportional |
| Max. wind speed | 28 mph |
| Battery | 4 x 6V 225Ah |
| Platform width | 3 ft 9 in |
